Architecture

One framework,every architecture.

Navree builds every shape of backend from the same unit: the module. Arrange modules one way and you have a modular monolith; another way, and you have services, a multi-tenant SaaS or an event-driven system. Start as one binary and change shape later without rewriting a module.

Choose an architecture How modules work

01 Modular monolith

One binary, hard boundaries.

Every feature is a module that declares what it imports, provides and exports. The app ships as one binary with one database, calls between features are function calls, and the kernel refuses to boot when a module reaches for something it wasn't given.

A modular monolith

request
imports

src/modules/deals/mod.rs

#[module(
    imports = [CompaniesModule],
    providers = [DealService],
    controllers = [DealsController],
    exports = [DealService],
)]
pub struct DealsModule;

Choose it when

You're starting. Every Navree app begins here.
One team, or several teams on one release.
A request touches three features and should commit once.

How Navree supports it

#[module] with imports, providers, controllers and exports
A type-keyed DI container, checked at boot and by check in CI
navree make:module writes a module and registers it
A crate per module when teams want Cargo to hold the lines

Modular monolith guide

02 Microservices

Split out a service. Keep the module.

A module that needs its own deploys, scaling or on-call moves into a binary of its own. Services answer messages and react to events over NATS, Kafka, RabbitMQ, Redis Streams, MQTT, TCP or gRPC, each owns its database, and a message handler is written like a route.

Microservices

request-response
event

services/deals/src/handlers.rs

#[message_handlers]
impl DealsHandlers {
    #[message_pattern("deals.get")]
    #[can(Read, Deal, from = "id")]
    async fn get(&self, uow: Uow, deal: Authorized<Deal, Read>) -> Result<DealView> {
        self.deals.view(&uow, deal.into_inner()).await
    }
}

Choose it when

One feature scales or ships unlike the rest.
A feature's failures or data must be kept apart.
A team owns a feature end to end, on-call included.

How Navree supports it

MicroModule, with the transport in configuration
#[message_pattern] and #[event_pattern] handlers with guards, #[can] and a unit of work
ServiceClient::send and emit, with an outbox for events
Request id, caller, workspace and trace context on every message

Microservices guide

03 Multi-tenant SaaS

Every customer gets a workspace.

Workspaces, members, roles and invitations are part of the framework and on by default. Each request resolves its workspace, checks membership and scopes its unit of work, so every query sees one customer's data, with PostgreSQL row-level security underneath.

Multi-tenancy by workspace

request

config/app.toml

[workspace]
resolvers = ["header", "path"]
# row | schema | database
isolation = "row"

[workspace.roles.member]
permissions = ["projects.*"]

Choose it when

Many organizations share one deployment.
Roles differ per customer: an owner here, a viewer there.
Some customers need their own schema or database.

How Navree supports it

WorkspaceModule, in the default features
The CurrentWorkspace extractor and WorkspaceRepo
Isolation by row, schema or database, set in configuration
Workspace roles feed #[permissions] and #[can]

Multi-tenant SaaS guide

04 Event-driven

React to changes without coupling modules.

Modules emit typed events and listeners react, in the request or on a worker. Jobs and outgoing events are written in the same transaction as the change and leave only after it commits, so nothing hears about a change that rolled back.

Event-driven, with an outbox

in the request
after the commit

crates/crm-deals/src/lib.rs

impl DealsModule {
    fn wire(&self, m: &mut ModuleBuilder) {
        m.listen::<DealAssigned, NotifyDealOwner>()
            .on::<DealWon, NotifyDealOwner>();
        m.forward_event::<DealWon>(); // also publish deal.won to other services
    }
}

Choose it when

Side effects must not slow or fail the request.
Screens should update live.
Other services must hear about every committed change.

How Navree supports it

Typed events (Event) and m.listen::<E, L>()
Queued listeners and jobs on queue:work, with retries and backoff
A transactional outbox: jobs and micro_outbox rows commit with the change
Broadcasting over the built-in Pusher-protocol WebSocket server

Event-driven guide

05 API-first

The contract comes from the code.

Routes declare their version and access rule, inputs are validated DTOs, outputs are typed resources and every error has one JSON shape. Navree builds an OpenAPI 3.1 document from all of it at boot, so the document, the validation and the generated clients change together.

API-first

generated from

crates/crm-deals-v2/src/lib.rs

#[controller("/deals", version = "2")]
impl DealsV2Controller {
    #[get("/{id}")]
    #[can(Read, Deal, from = "id")]
    #[api(summary = "Show a deal", response = DealV2Resource, responses(401, 403, 404))]
    async fn show(
        &self,
        uow: Uow,
        deal: Authorized<Deal, Read>,
    ) -> Result<Json<DealV2Resource>> {
        let deal = self.deals.show(&uow, deal.into_inner()).await?;
        Ok(Json(deal.into()))
    }
}

Choose it when

Mobile apps, partners, other teams or AI agents use your API.
A breaking change should fail CI, not a client.
The docs must never drift from the code.

How Navree supports it

#[controller("/deals", version = "1")] and #[api(...)]
Valid<Json<T>> with garde rules: field errors before the handler runs
ApiModule serves /api/openapi.json and /api/docs
openapi:export for typed clients in any language

API-first guide

06 Backend for frontend

Keep every token out of the browser.

Your web app talks only to its own server, on the same origin. That server keeps the access and refresh tokens in httpOnly cookies, rotates them and calls the Navree API with a bearer token. The API stays the plain bearer-token API every other client uses.

Backend for frontend

request
real-time event

src/app/api/[...path]/route.ts

import { bff } from "@/lib/bff/server";

/** Every /api/* call is forwarded with the bearer token from the httpOnly cookie. */
function handle(request: Request): Promise<Response> {
  return bff.proxy(request, new URL(request.url).pathname);
}

export { handle as DELETE, handle as GET, handle as PATCH, handle as POST, handle as PUT };

Choose it when

You ship your own web app.
One cross-site scripting bug must not leak every session.
Mobile apps and partners call the same API with tokens.

How Navree supports it

Refresh tokens that rotate on every use, with reuse detection
A Next.js BFF in the saas starter kit and navree new --ui next
Real time straight from the WebSocket server, channels authorized through the BFF
A browser client generated from the OpenAPI document

Backend for frontend guide

Grow without rewriting

Start as one binary. Grow into the shape the product needs.

A module keeps its providers, rules, migrations and tests whether it runs in the monolith, inside a workspace or in a service of its own. What changes is the wiring around it.

Step 1
Start as a modular monolith
navree new writes one binary, and make:module adds a module per feature. Calls between features are function calls, and one transaction covers a request.
Terminal
```
navree new crm
navree make:module companies --crud
navree make:module deals --crud
```
Step 2
Add workspaces
Add WorkspaceModule, give tenant tables a workspace_id and take CurrentWorkspace where a handler needs it. Routes, services and access rules stay as they are.
src/app.rs
```
.module(AuthModule::from_config())
.module(WorkspaceModule::from_config())
.module(CompaniesModule)
.module(DealsModule)
```
Step 3
Move a module into a service
When deals need their own deploys, DealsModule moves into its own binary with MicroModule. Its service, rules and tests come along; callers send a message instead of calling a method.
src/modules/reports/service.rs
```
self.deals.show(&uow, id).await?
self.client
    .send("deals.get", &GetDeal { id })
    .await?
```

What changes: The wiring: which binary a module runs in, its transport, the isolation of its tables, how callers reach it.
What stays: Every line of module code: its services, routes and handlers, its access rules, its migrations and its tests.

Start

Start from the shape you need.

Each starter kit is a working app in one of these shapes, built from the same modules as everything on this page.

Multi-tenant SaaS
Workspaces, billing and an admin panel, with a Next.js BFF that keeps tokens in httpOnly cookies.
$ navree new acme --kit saas
API-first monolith
Versioned routes, an OpenAPI 3.1 document and a module per feature, ready for any client.
$ navree new acme --kit api
Microservice
One module with a message handler, an event handler and NATS configured for development.
$ navree new deals --kit micro

Explore the starter kits Read the patterns guide
